Digital RCD/ELCB Tester

SKU: MT325

  • Double injection housing
  • Correct wiring indication
  • 2000ms Direct readout of disconnection time
  • Fully programmed test current settings
  • Accurate readout of tripping time with a resolution of 1ms
  • Two LED lamps give quick check for correct wiring
  • Compact, lightweight and simple to use
  • 0° or 180° Phase angle selection
  • Current setting from 5mA to 500mA
  • Operating voltage 216V AC – 264V AC
  • Data Hold function to freeze the digital trip time on the LCD

$ 235.00 ex. GST $ 258.50 in. GST
Add to Quote Find a Distributor

Details

The compact MT325 is a lightweight and easy to use ELCB Tester that operates on 216V AC – 264V AC circuits while offering high accuracy measurements. Features include pre-programmed tripping current ranges for speed of use, with direct readout of disconnection time with a resolution of 1ms, neon indication of correct wiring status. Consistent results are obtained with the 0° and 180° phase angle select switch, thus eliminating the need for repeat tests.

Specifications:

Function Range Accuracy
Voltage Measurement 220V AC to 240V AC ± (3%)
Frequency Response 50/60Hz
Test Current 5,10,30,100,300,500mA
Measuring Range  2000ms ± (5%)
Phase Angle Selection 0° or 180°
Socket Polarity Yes
Enclosure Double Injection moulding
Display LCD
Weight 130g
Dimensions 130 x 69 x 32mm
Safety Specs IEC61010-1 CAT III 600V

Safety Rating

Warranty

Accessories:

  • Instruction Manual
