18 Pole Surface Mount IP66 Weatherproof Switchboard

SKU: VBW18SA

  • IP66 Waterproof & Dustproof
  • Single-row Height
  • 18-Pole - 18 individual 18mm modules
  • IK08 Rating
  • 850°C Fire Resistence for 30 seconds
  • Surface Mount
  • Material
    • DB box shell: Polycarbonate (PC)
    • Earth/Neutral bar: copper
  • Standard: AS/NZS 61439 and AS/NZS 61000
  • Approval: CE, RoHS, HF test, IK test, ISO 9001

$ 99.00 ex. GST $ 108.90 in. GST

Details

An IP66 electrical distribution board offers superior protection for electrical circuits in harsh environments. Rated IP66, it is completely dust-tight and can withstand powerful water jets from any direction, making it ideal for outdoor and industrial use. Constructed from robust materials with sealed enclosures, the IP66 and IK08 impact resistant shell safeguards against dust, moisture, and impacts. When equipped with circuit breakers, earth leakages, and isolator switches, this distribution board ensures reliable protection against overloads and faults. Suitable for factories, marine settings, and areas prone to extreme weather, the IP66 distribution board ensures durability and safety, maintaining optimal performance even in challenging conditions.



Specifications:

Function

Range

Pole

18 of 18mm modules

Rows

1

Dimensions

230 x 380 x 115mm

Mount

Surface

Mounting Support

Din Rail

Knock Outs

Top

Bottom



4xØ20mm & 4xØ32mm

4xØ20mm & 4xØ32mm

IP Rating

IP66

IK Rating

IK08

Fire Resistant

Up to 850°C / 30s

Material

Enclosure

Earth/Neutral Bar



High Quality Polycarbonate Plastic

Copper

Safety Rating

Warranty
